The BS300-02 Dust Sensor uses advanced laser scattering technology to accurately detect and measure dust particle concentration in the air. It is capable of identifying particles as small as 1.0 μm, ensuring reliable monitoring performance with excellent consistency and long-term stability. Designed for a wide range of applications, the BS300-02 is available in both indoor and outdoor models to suit different environmental conditions and installation requirements.
Specifications
Item | Specifications |
Sampling Object | PM1.0, PM2.5, PM10 Concentration |
Range | 0 ~ 1000μg/m3 |
Accuracy | ±3%FS@25°C |
Warm Up Time | 3 min |
Response Time | <60s |
Temperature Drift | ≤0.2%FS/°C |
Stability | <±2%FS |
Repeatability | <±1%FS |
Output | 4 ~ 20mA, 0 ~ 5V, 0 ~ 10V, RS-485 |
Operating Voltage | 5VDC,12 ~ 24VDC |
Power Consumption | <50mA@24V(4 ~ 20mA) |
Operating Temperature | -20°C ~ 50°C@15 ~ 80%RH |
Storage | -40 ~ 60°C@20% ~ 60%RH |
Shell Material | ABS |
Public Place
Warehousing
Air Ǫuality Monitoring
Smart Home
