Introduction to Sensor
Specifications
Specifications
General Specifications
| Parameter | Specification |
|---|---|
| Length | 110 mm |
| Diameter | 22 mm |
| Memory | 72,000 measurements with backup |
| Weight | 104 g |
| Housing | Stainless Steel 316L |
| Battery Life | Up to 10 years (depending on usage) |
| Sample Interval | 0.5 seconds to 99 hours |
| Sample Method | Fixed interval |
Pressure Specifications
| Parameter | DI800 |
|---|---|
| Range | 1.5 m |
| Accuracy* | ±0.5 cmH₂O |
Temperature Specifications
| Parameter | Value |
|---|---|
| Range | -20 to +80 °C |
| Accuracy* | ±0.1 °C |
| Resolution | 0.01 °C |
* Typical values.
Features
Applications
